4 Mode USB Bike Light Lamp Bicycle Computer 3 Mode Horn Flashlight Cycle Bike Speedometer Led Front Lights Cycling Headlight

Do you want to get a bright bike light to ride at night ?
Do you want to warn other cars or riders during cycling at night ?
Do you want a cycling odometer to achieve your fitness goals ?
Do you want a loud bike bell to make others be warning ?
Did your handlebar is not enough spare for all of the gadgets ?

Features

800 Lumens Bike headlight gives you awesome visibility and keep safe distance in the dark.
Bike speedometer with accurate tracking on speed and distance helps you to get more fun of your cycling trip or easily achieve your fitness goals.

120dB speaker provide a clear warning for passers-by riders and cars.
Please enjoy cycling with this wonderful gadget in the anytime to feel your speed!

Specifications

Name：NEWBOLER Bike Computer Horn Light
Model: BK-1920
Headlight brightness: 800 lumens
Lighting mode: High/Low/Flash
Effective range: 200m
Electronic horn: About 120 dB Lamp
Light working time: 5hrs/10hrs
Computer working time: 3000hrs
Rechargeable Battery: 4000mAh
Charging mode: USB charging
Recharge time: 4hrs
Sensor battery: CR2032
Sensor working time: 12months, 1hr/day
Waterproof: IP65
Weight: about 145g
Size: about 110*40* 35mm
Color: Red / Blue / Green / Black

How to install the magnet and launcher

The best installation position of the magnet is on the top of the bicycle spoke. The top of the bicycle spoke has a non-circular structure. After the magnet is locked, it will not swing back and forth, and the wireless signal is stable.

The distance between the magnet and the sensor should be kept at about 6mm. If it is too close, it may become unstable.
The magnet corresponds to the center position of the transmitter liked the picture showed, and the signal is more stable and accurate.
Wireless launcher needs a 2032 button cell.

4 Colors are optional

Configuration

( 1 ) Main Unit
( 2 ) Bracket
( 3 ) Spoke Magnet
( 4 ) Installation Kit
( 5 ) Speed Sensor
( 6 ) Lighting And Sound Extension Controller
( 7 ) Extension Controller Fixed Strap
( 8 ) Zip Ties
( 9 ) USB Charging Cable
(10) Central bracket (Optional)
(11) Bike Tail light (Optional)

Details Setting

[1]
Enter the tire perimeter setting, press the MODE key to set the value from left to right, and press the SET key to change the value. A total of four values need to be set in millimeters.
[2]
Enter the metric/imperial setting, press SET to switch between metric/imperial units, and press MODE to confirm.
[3]
Weight setting, press the SET key to set the value from left to right, the unit is KG, press the MODE key to confirm.
[4]
Clock setting: press the set key to set the value, press the MODE key to switch the next bit,
[5]
Reserve the location of the setting, please ignore this setting
[6]
When the settings are complete, press the power key to exit the settings

Tyre size correspondence table

Important Tips

For possible reading inaccuracies, customers should know the following information
1. the distance between monitor and sensor should below 80 cm
2. the distance between sensor and magnetic should below 3 mm
3. In order to enhance anti-interference, we used ID coding technology in the design. When the battery is just installed, the speed sensor needs to work continuously for 1 minute to recognize the new sensor.Please refer to the video and test for one minute, then check if the speed sensor is working properly
4. The wrong installation of the speed sensor will also cause 0 display. please refer to the picture below to make sure the installation is right.
By the way, this bicycle computer is a wireless product, and the electromagnetic waves of the environment will affect its normal operation.
When using it, we should avoid the electrical equipment at work: household appliances, high-voltage wires, transformers, high-voltage cables, charging stations, elevators and other electrical equipment at work (code table speed display 0 when interfered by them)
5.The Data Sensor consists of a receiver and a magnet. To accurately measure the data, the sensor must be fixed firmly. The receiver should be aligned with the magnet at the same level.

07.30.2020, Customer C , there is no data at all, the computer can not find the sensor.
[A]:it is suggested the disctance between the sensor and computer should be below 100cm .The sensor can be installed on the front fork, and the top of the front fork, it will be connected in good condition.

08.05.2020, Customer D , the speed turn to 99km/h sometimes.
[A]:The installation is not correct. we suggested reboot the computer , then set the correct tire circumference . and make sure that the magnet is aligned with the center of the sensor,please see the picture below. If the magnet is aligned with the corner of the sensor, the magnet attraction is not accurate enough, and it is prone to abnormal speed。
